IM41GR TE Connectivity IM41GR label picture IM41GR label picture 1 IM41GR real image 2 IM41GR label picture 3 IM41GR real image 3
Same model may have multiple batches, images only for reference.
IM41GR TE Connectivity IM41GR label picture IM41GR label picture 1 IM41GR real image 2 IM41GR label picture 3 IM41GR real image 3
IM41GR TE Connectivity IM41GR label picture IM41GR label picture 1 IM41GR real image 2 IM41GR label picture 3 IM41GR real image 3
Same model may have multiple batches, images only for reference.

IM41GR

Part No IM41GR
Manufacturer TE Connectivity
Catalog Signal Relays, Up to 2 Amps
Description RELAY TELECOM DPDT 2A 3V
Datasheet
IM41GR Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Relays
Manufacturer TE Connectivity Potter & Brumfield Relays
Packaging Reel - TR
Status Active
Relay Type Telecom
Coil Type Latching, Single Coil
Coil Current 33.3mA
Coil Voltage 3VDC
Contact Form DPDT (2 Form C)
Contact Rating (Current) 2A
Switching Voltage 250VAC, 220VDC - Max
Turn On Voltage (Max) 2.25 VDC
Operate Time 3ms
Release Time 3ms
Features Sealed - Hermetically
Mounting SMD (SMT)
Termination Style Gull Wing
Coil Power 100 mW
Coil Resistance 90 Ohms
Temperature Range - Operating -40°C to 85°C
Win Source Part Number 205146-IM41GR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian IM41GR CAD Model

Description

The TE Connectivity Potter & Brumfield Relays 205146-IM41GR is a DPDT (2 Form C) telecom relay with a gull wing termination style.

  • Product Name: TE Connectivity Potter & Brumfield Relays 205146-IM41GR
  • Relay Type: DPDT (2 Form C) telecom relay
  • Termination Style: Gull wing
  • Design: Sealed-hermetically
  • Mounting: SMD (SMT)
  • Coil Resistance: 90 Ohms
  • Coil Voltage: 3VDC
  • Contact Rating (Current): 2A
  • Switching Voltage: 250VAC and 220VDC
  • Operate Time: 3ms
  • Release Time: 3ms
  • Relay Type: Latching, single coil
  • Coil Current: 33.3mA
  • Coil Power: 100mW
  • Market Status: Popular and commonly used with high demand
