Same model may have multiple batches, images only for reference.
T92P7D12-12 TE Connectivity
Same model may have multiple batches, images only for reference.

T92P7D12-12

Part No T92P7D12-12
Manufacturer TE Connectivity
Catalog Power Relays, Over 2 Amps
Description RELAY GEN PURPOSE DPST 30A 12V
Datasheet
T92P7D12-12 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Relays
Manufacturer TE Connectivity Potter & Brumfield Relays
Packaging Bulk
Status Active
Relay Type General Purpose
Coil Type Non Latching
Coil Current 141.67mA
Coil Voltage 12VDC
Contact Form DPST (2 Form A)
Contact Rating (Current) 30A
Switching Voltage 277VAC, 28VDC - Max
Turn On Voltage (Max) 9 VDC
Turn Off Voltage (Min) 1.2 VDC
Operate Time 15ms
Release Time 15ms
Features Insulation - Class F
Mounting Through Hole
Termination Style PC Pin
Coil Power 1.7 W
Coil Resistance 86 Ohms
Temperature Range - Operating -55°C to 85°C
Win Source Part Number 212537-T92P7D12-12
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian T92P7D12-12 CAD Model

Description

The TE Connectivity Potter & Brumfield Relays 212537-T92P7D12-12 is an active electronic component that comes with a termination style of PC pin and an insulation - class F feature.

  • Termination Style: PC Pin
  • Insulation: Class F
  • Contact Form: DPST (2 Form A)
  • Mounting Style: Through Hole
  • Coil Resistance: 86 Ohms
  • Coil Current: 141.67mA
  • Operate Time: 15ms
  • Release Time: 15ms
  • Relay Type: General Purpose
  • Coil Type: Non-Latching
  • Contact Rating (Current): 30A
  • Switching Voltage: Up to 277VAC and 28VDC - Max
  • Turn On Voltage (Max): 9VDC
  • Turn Off Voltage (Min): 1.2VDC
  • Coil Power: 1.7W
  • Supply and Demand Status: Limited
