The Texas Instruments ADS1120IRVAR is a precision, low-power, 16-bit analog-to-digital converter (ADC) that offers a wide array of features designed to meet the rigorous requirements of industrial, instrumentation, and temperature sensing applications. This ADC is notable for its impressive combination of high performance and small form factor, making it an ideal choice for space-constrained designs.

Key Features

• Precision Performance: With 16-bit resolution and a highly accurate internal oscillator, the ADS1120IRVAR provides precise measurements with minimal external components required.
• Low Power Consumption: It operates with a supply range from 2.3V to 5.5V, allowing for efficient power management in battery-operated and energy-conscious systems.
• Flexible Data Rate: The device supports data rates up to 2000 samples per second (SPS), giving designers the flexibility to balance speed and power consumption according to their application needs.
• Programmable Gain Amplifier (PGA): An onboard PGA offers gains from 1 to 128, which is particularly useful for small-signal measurements, enhancing the dynamic range and sensitivity of the system.
• Multiple Interface Options: The ADS1120IRVAR features an I²C-compatible serial interface, allowing for easy integration into a wide range of microcontroller-based systems.
• Integrated Features: It includes features such as an external reference input, oscillator, temperature sensor, and burnout current sources, providing a high level of integration that simplifies design and reduces external component count.

Applications

The ADS1120IRVAR is well-suited for a variety of applications, including:

• Process control and automation
• Temperature measurement and control systems
• Portable instrumentation
• Medical devices
• Battery-powered equipment

With its combination of precision, integration, and efficiency, the Texas Instruments ADS1120IRVAR ADC is a robust solution for designers looking to improve the accuracy and performance of their data acquisition systems.
