ADS7866IDBVR Real Image ADS7866IDBVR Real Image1 ADS7866IDBVR Real Image2 ADS7866IDBVR Real Image3 ADS7866IDBVR Real Image4
ADS7866IDBVR Real Image ADS7866IDBVR Real Image1 ADS7866IDBVR Real Image2 ADS7866IDBVR Real Image3 ADS7866IDBVR Real Image4
Same model may have multiple batches, images only for reference.

ADS7866IDBVR

Part No ADS7866IDBVR
Manufacturer Texas Instruments
Catalog Data Acquisition - Analog to Digital Converters (ADC)
Description IC ADC 12BIT 200KSPS SOT23-6
Datasheet
ADS7866IDBVR Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Number of Bits 12
Sampling Rate 200k
Number of Inputs 1
Input Type Single Ended
Data Interface SPI
Configuration S/H-ADC
Number of A/D Converters 1
Reference Type External
Analog Supply Voltage 1.2 V to 3.6 V
Digital Supply Voltage 1.2 V to 3.6 V
Temperature Range - Operating -40°C to 85°C
Case / Package SOT-23-6
Win Source Part Number 009350-ADS7866IDBVR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian ADS7866IDBVR CAD Model

Description

Product Overview

The ADS7866IDBVR is a low-power, single-channel ADC with a stellar combination of performance and precision. Ideal for use in various data logging and sensor measurement systems, it exhibits excellent functionality in space-limited environments.

Features and Benefits

  • 10-bit resolution enhancing measurement accuracy
  • Low power consumption optimized for battery-powered devices
  • Compact 6-lead SOT-23 package
  • Single-supply operation from 2.7 V to 5.5 V

Applications

  • Portable data loggers
  • Environmental monitoring devices
  • Consumer electronics
  • Signal conditioning applications

Additional Details

The ADS7866IDBVR is engineered to deliver robust performance in precision-demanding applications. Its ultra-low power feature makes it an ideal choice for devices operating on limited power budgets.
