The BQ24105IRHLRQ1 is a sophisticated charging solution from Texas Instruments, designed to cater to the needs of modern electronics requiring efficient and reliable battery management. This integrated circuit is specifically tailored for automotive applications, offering a robust feature set that ensures optimal performance in a variety of conditions.

Key Features

• Advanced Charge Management: The BQ24105IRHLRQ1 offers a highly efficient switch-mode charge management solution, which is capable of charging one to four series Li-Ion and Li-Polymer cells.
• Adaptive Supply Management: This IC supports USB and adapter power, with a programmable input current limit to comply with USB specifications and a wide input voltage range suitable for car battery supplies.
• High Accuracy: The charging parameters are highly accurate, including voltage, current, and temperature monitoring to ensure safe and precise charging of the battery.
• Temperature Range: Designed for the automotive industry, the BQ24105IRHLRQ1 can operate in an extended temperature range, making it reliable in harsh environments.
• Safety Features: It includes multiple safety features such as overvoltage protection, thermal shutdown, and a timer for charge termination to prevent damage to the battery and the device.

Applications

The BQ24105IRHLRQ1 is ideal for a wide range of automotive applications where efficient and secure battery charging is crucial. It is commonly used in:

• Infotainment Systems
• Navigation Units
• Backup Battery Systems
• Portable Electronic Devices

Package and Quality

Packaged in a compact 20-pin QFN (RHL), the BQ24105IRHLRQ1 is designed for space-constrained applications. It meets the rigorous AEC-Q100 standards for automotive quality, ensuring high reliability and performance longevity.
