CC2420RGZR Real Image CC2420RGZR Real Image
Same model may have multiple batches, images only for reference.
CC2420RGZR Real Image CC2420RGZR Real Image
CC2420RGZR Real Image CC2420RGZR Real Image
Same model may have multiple batches, images only for reference.

CC2420RGZR

Part No CC2420RGZR
Manufacturer Texas Instruments
Catalog RF Transceiver ICs
Description IC RF TXRX 802.15.4 48-VFQFN
Datasheet
CC2420RGZR Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories RF/IF and RFID
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Type TxRx Only
RF Family/Standard 802.15.4
Protocol Zigbee
Modulation DSSS, O-QPSK
Frequency 2.4GHz
Data Rate (Max) 250kbps
Power - Output 0dBm
Sensitivity -95dBm
Serial Interfaces SPI
Supply Voltage - Operating 2.1 V to 3.6 V
Current - Receiving 18.8mA
Current - Transmitting 8.5mA to 17.4mA
Temperature Range - Operating -40°C to 85°C
Dimension 48-VFQFN Exposed Pad
Win Source Part Number 012762-CC2420RGZR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name CC2420
Country of Origin Philippines
Halogen Free Compliant
Estimated EOL Date 2028
Ultra Librarian 3D Model Ultra Librarian CC2420RGZR CAD Model

Description

Overview of CC2420RGZR

The CC2420RGZR is a 2.4 GHz IEEE 802.15.4/ZigBee RF transceiver designed to provide superior wireless networking applications. Manufactured with precision to ensure excellent performance, this component is ideal for those seeking to enhance their wireless technology solutions.

Features and Benefits

  • Operates in the 2.4 GHz unlicensed ISM band.
  • Low current consumption: RX (19.7 mA) and TX (17.4 mA).
  • Industry-standard 802.15.4 complaint, supporting the ZigBee protocol.
  • High sensitivity and robustness to interference, improving communication reliability.

Applications

  • Home and building automation systems.
  • Industrial monitoring and control solutions.
  • Wireless sensor networks (WSNs).
  • Remote control and surveillance systems.

With these advantages, the CC2420RGZR is a versatile choice for various wireless communication projects, offering stable and efficient connections.
