The CD74HC123M96G4 is a high-speed CMOS logic Dual Retriggerable Monostable Multivibrator manufactured by Texas Instruments. This integrated circuit is designed to be used in applications requiring precise timing and pulse generation, such as in digital communication systems, data processing, instrumentation, and control systems.

Key Features

• High-Speed Performance: The CD74HC123M96G4 operates at a high speed, making it suitable for fast systems and ensuring minimal propagation delays.
• Wide Operating Voltage: It features a wide operating voltage range from 2V to 6V, providing flexibility in various power environments and compatibility with TTL levels.
• Low Power Consumption: This device is designed for low power consumption, making it ideal for battery-operated and power-sensitive applications.
• Dual Monostable Multivibrator: The dual configuration allows for two independent timing operations within a single package, optimizing space and reducing the need for additional components.
• Retriggerable: The multivibrator is retriggerable, meaning it can reset and start a new timing cycle before the current cycle has completed, providing versatility in timing design.
• Balanced Propagation Delays: The device is designed to have balanced propagation delays, which is crucial for maintaining timing accuracy in high-speed systems.

Applications

The CD74HC123M96G4 is versatile and can be used in a variety of applications, including:

• Timing circuits
• Pulse shaping
• Missing pulse detection
• Sequential systems
• Envelope detection

Package Information

The device is available in a compact SOIC-16 package, which is suitable for surface-mount technology (SMT). Its small footprint allows for high-density mounting and is ideal for space-constrained applications.

Quality and Reliability

Texas Instruments is known for its commitment to quality and reliability. The CD74HC123M96G4 is built to meet high standards, ensuring stable performance and a long operational life in a variety of environmental conditions.
