CD74HC154M96G4

Part No CD74HC154M96G4
Manufacturer Texas Instruments
Catalog Logic - Signal Switches, Multiplexers, Decoders
Description IC DECODER/DEMUX 1X4:16 24SOIC / Decoder/Demultiplexer 1 x 4:16 24-SOIC
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Integrated Circuits (ICs)>Logic - Signal Switches, Multiplexers, Decoders
Mfr Texas Instruments
Series 74HC
Package Tape & Reel
Type Decoder/Demultiplexer
Independent Circuits 1
Current - Output High, Low 5.2mA, 5.2mA
Voltage Supply Source Single Supply
Voltage - Supply 2V ~ 6V
Temperature Range - Operating -55°C ~ 125°C
Mounting SMD (SMT)
Package / Case 24-SOIC (0.295", 7.50mm Width)
Supplier Device Package 24-SOIC
Base Product Number 74HC154
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Other Names CD74HC154M96G4-ND,296-48900-6,296-48900-2,296-48900-1
Standard Package 2,000
Win Source Part Number 1206572-CD74HC154M96G4
Ultra Librarian 3D Model Ultra Librarian CD74HC154M96G4 CAD Model

Description

Product Overview: CD74HC154M96G4

The CD74HC154M96G4 is a high-performance integrated circuit from Texas Instruments, known for its reliability and versatility in digital systems. This particular chip is a 4-to-16 line decoder/demultiplexer that belongs to the HC family, which signifies the use of silicon-gate CMOS technology. The device is designed to facilitate the decoding of four binary-coded inputs into one of sixteen mutually exclusive outputs when both the strobe inputs, G1 and G2, are held low.

Key Features

  • High-Speed CMOS Logic: Operates at speed parameters matching LSTTL logic, with the added benefit of CMOS lower power consumption.
  • Operating Voltage Range: The CD74HC154M96G4 works within a 2V to 6V VCC operating voltage range, making it suitable for various applications.
  • Output Drive Capability: Capable of driving 15 LSTTL loads, ensuring compatibility with a wide range of digital components.
  • Low Power Consumption: Its typical low power consumption of 80µA significantly reduces overall system power requirements.
  • High Noise Immunity: Characteristic of the HC family, the device possesses a noise immunity consistent with standard CMOS ICs.

Applications

The CD74HC154M96G4 is ideal for hardware applications where a compact and efficient means of decoding or de-multiplexing signals is required. It is often used in:

  • Memory decoder circuits
  • Data routing applications
  • Control interface systems
  • Computer logic systems

Quality and Reliability

Texas Instruments ensures that the CD74HC154M96G4 meets stringent quality and reliability standards. The device is available in a surface-mount package, specifically the SOIC-24, which is conducive to automated assembly processes. With its industrial-grade design, the CD74HC154M96G4 is suitable for operation in a broad range of environmental conditions.

Whether your project involves complex computing systems or simple logic operations, the CD74HC154M96G4 from Texas Instruments provides a reliable solution for your decoding and de-multiplexing needs with its robust design and high functionality.
