CSD16409Q3 Real Image CSD16409Q3 Real Image1 CSD16409Q3 Real Image2
Same model may have multiple batches, images only for reference.
CSD16409Q3 Real Image CSD16409Q3 Real Image1 CSD16409Q3 Real Image2
CSD16409Q3 Real Image CSD16409Q3 Real Image1 CSD16409Q3 Real Image2
Same model may have multiple batches, images only for reference.

CSD16409Q3

Part No CSD16409Q3
Manufacturer Texas Instruments
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 25V 60A 8-SON
Datasheet
CSD16409Q3 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 25V
Continuous Drain Current at 25°C 15A (Ta), 60A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
Gate-Source Threshold Voltage 2.3V @ 250μA
Max Gate Charge 5.6nC @ 4.5V
Max Input Capacitance 800pF @ 12.5V
Maximum Gate-Source Voltage +16V, -12V
Power Dissipation (Max) 2.6W (Ta)
Maximum Rds On at Id,Vgs 8.2 mOhm @ 17A, 10V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package 8-VSON (5x6)
Dimension 8-PowerTDFN
Win Source Part Number 013353-CSD16409Q3
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian CSD16409Q3 CAD Model

Description

CSD16409Q3 - Power MOSFET

The CSD16409Q3 is a well-designed power MOSFET that offers superior performance in compact electronic applications. It's best suited for high-efficiency power conversion and management systems.

  • Applications:
    • High-efficiency DC-DC Conversion
    • Telecom Infrastructure
    • Portable Equipment
  • Features and Benefits:
    • Low gate charge for fast switching
    • High-speed performance
    • Small QFN package for design flexibility
  • Additional Details:
    • Maximum Drain-Source Voltage: 30V
    • Maximum Continuous Drain Current: 55A
