Product Overview: CSD86336Q3D NexFET™ Power Block from Texas Instruments

The CSD86336Q3D is a state-of-the-art power block device manufactured by Texas Instruments, renowned for its high efficiency and performance in power management applications. This product is part of the NexFET™ series, which is designed to deliver optimal power solutions in a compact package.

Key Features

• High-Density Power Block: The CSD86336Q3D is a dual NexFET™ power MOSFET that provides high power density, making it ideal for space-constrained applications.
• Advanced Packaging: This device comes in a small 3.3mm x 3.3mm SON package with an exposed thermal pad, ensuring excellent thermal performance and a low on-resistance.
• Efficiency: With its low gate charge and low drain-to-source on-resistance, this power block is engineered for high efficiency, reducing power loss and improving overall system performance.
• Integrated Driver: The CSD86336Q3D includes an integrated driver that simplifies the design process and helps in reducing external component count.

Applications

The versatility of the CSD86336Q3D makes it suitable for a wide range of applications, including:

• Synchronous buck converters
• Point of Load (POL) modules
• DC/DC converters for server, telecom, and networking equipment
• High-density power supplies

Technical Specifications

Below are some of the technical specifications for the CSD86336Q3D:

• Voltage Rating: 25V
• Continuous Drain Current: 40A
• Power Dissipation: 3.2W
• Operating Temperature Range: -55°C to 150°C

With its exceptional power handling capabilities and compact form factor, the Texas Instruments CSD86336Q3D NexFET™ Power Block is a top choice for designers looking to optimize their power management systems.
