The DRV8828PWPR, from the renowned semiconductor manufacturer Texas Instruments, is a versatile integrated circuit designed for driving bipolar stepper motors. This compact, high-performance motor driver is suitable for a wide range of applications, including but not limited to printers, scanners, digital cameras, gaming machines, and robotics.

Key Features

• Supply Voltage: The device operates from a supply voltage range of 8.2 V to 45 V, making it suitable for various industrial and commercial applications.
• Output Current: It can deliver up to 2.5 A of output current per coil, with the current being adjustable through an external current-sense resistor.
• Microstepping: The DRV8828PWPR supports up to 1/16 microstepping, enabling precise motor control for smooth and accurate positioning.
• Protection Features: It includes multiple protection features such as overcurrent, thermal shutdown, and under-voltage lockout, ensuring reliable operation and safeguarding the device from potential damage.
• Control Interface: The motor driver is controlled via a simple step and direction interface, providing ease of use for system integrators and designers.
• Package: It comes in a 16-pin HTSSOP package with PowerPAD™ for enhanced thermal performance.

Applications

The DRV8828PWPR's robust design and feature set make it an ideal choice for driving stepper motors in a variety of applications. Its precise control capabilities are particularly beneficial in applications requiring accurate positioning and smooth motion profiles.

Design Resources

Texas Instruments offers comprehensive design resources to support the DRV8828PWPR, including datasheets, application notes, and evaluation modules. These resources are designed to accelerate the design process, from initial concept to final product, and ensure the successful integration of the motor driver into your application.

With its combination of performance, versatility, and reliability, the DRV8828PWPR stepper motor driver from Texas Instruments stands out as an excellent choice for designers looking to enhance the capabilities of their motor-driven applications.
