The DS2003CMX is a versatile and robust integrated circuit from Texas Instruments, designed to cater to a wide array of applications requiring multiple high-voltage outputs. This component is a member of Texas Instruments' high-performance CMOS line and is engineered to provide the functionality of seven high-voltage, open-collector Darlington pairs with common emitters in a single package.

Key Features

• High-Voltage Outputs: The DS2003CMX boasts high-voltage outputs with a 50V maximum rating, making it suitable for driving a variety of loads, including relays, solenoids, and other high-voltage devices.
• High Current Capability: Each Darlington pair can deliver a continuous output current of up to 500mA, providing the power necessary for demanding applications.
• Integrated Suppression Diodes: Built-in clamping diodes are provided for inductive transient suppression, which is essential for driving inductive loads and protecting the device from voltage spikes.
• Low Input Current Requirements: The Darlington pairs can be driven by standard TTL or CMOS logic signals, thanks to their low input current thresholds, making them easily interfaced with microcontrollers and other logic devices.

Applications

The DS2003CMX is a highly adaptable component suitable for a range of applications. It is commonly used in:

• Industrial control systems
• Relay drivers
• Stepper motor drivers
• LED displays
• Logic buffers

Package and Quality

The DS2003CMX is offered in an SOIC-16 package, providing a compact solution that is both space-saving and easy to integrate into various circuit designs. Texas Instruments is renowned for its commitment to quality, and this product is no exception. It is designed to meet stringent industry standards, ensuring reliability and performance in even the most demanding situations.

With its combination of high-voltage, high-current capabilities, and ease of use, the DS2003CMX from Texas Instruments is an ideal choice for designers looking to create efficient and reliable systems that require multiple output drivers.
