INA146UA Real Image INA146UA real image96
Same model may have multiple batches, images only for reference.
INA146UA Real Image INA146UA real image96
INA146UA Real Image INA146UA real image96
Same model may have multiple batches, images only for reference.

INA146UA

Part No INA146UA
Manufacturer Texas Instruments
Catalog Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description IC OPAMP DIFF 550KHZ 8SOIC
Datasheet
INA146UA Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Tube/Rail
Status Active
Amplifier Type Differential
Number of Circuits 1
Slew Rate 0.45 V/μs
-3db Bandwidth 550kHz
Current - Input Bias 50nA
Voltage - Input Offset 1mV
Operating Supply Current 570μA
Channel Output Current 15mA
Supply Voltage - Operating 4.5 V to 36 V, ±2.25 V to 18 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 8-SOIC
Win Source Part Number 001801-INA146UA
Family Name INA146
Introduction Date April 01, 2006
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2028
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian INA146UA CAD Model

Description

The INA146UA is a high-performance, precision instrumentation amplifier from Texas Instruments, a leading global semiconductor company.

  • Offset Voltage: 50µV
  • Offset Voltage Drift: 0.5µV/°C
  • Common-Mode Rejection Ratio (CMR): 114dB
  • Power Supply: from 2.7V to 36V, or from dual supplies of ±1.35V to ±18V
  • Slew Rate: 13V/µs
  • Bandwidth: 800kHz
