LM1117DTX-3.3 Texas Instruments LM1117DTX-3.3 Real Image LM1117DTX-3.3 Real Image1 LM1117DTX-3.3 Real Image2
Same model may have multiple batches, images only for reference.
LM1117DTX-3.3 Texas Instruments LM1117DTX-3.3 Real Image LM1117DTX-3.3 Real Image1 LM1117DTX-3.3 Real Image2
LM1117DTX-3.3 Texas Instruments LM1117DTX-3.3 Real Image LM1117DTX-3.3 Real Image1 LM1117DTX-3.3 Real Image2
Same model may have multiple batches, images only for reference.

LM1117DTX-3.3

Part No LM1117DTX-3.3
Manufacturer Texas Instruments
Catalog PMIC - Voltage Regulators - Linear
Description IC REG LDO 3.3V 0.8A TO252-3
Datasheet
LM1117DTX-3.3 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Output Type Fixed
Number of Regulators 1
Maximum Input Voltage 15V
Nominal Output Voltage (Min/Fixed) 3.3V
Dropout Voltage-Max 1.2V @ 800mA
Output Current 800mA
Operating Supply Current 5mA to 10mA
PSRR 75dB (120Hz)
Control Protection Features Over Current, Over Temperature
Temperature Range - Operating 0°C to 125°C
Regulator Topology Positive Fixed
Output Voltage 3.3V
Voltage - Dropout (Typical) 1.2V @ 800mA
Mounting SMD (SMT)
Case / Package TO-252-3
Win Source Part Number 091515-LM1117DTX-3.3
Family Name LM1117
Introduction Date June 01, 1998
ECCN EAR99
Country of Origin Malaysia
Halogen Free Not Compliant
Estimated EOL Date Obsolete
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian LM1117DTX-3.3 CAD Model

Description

The LM1117DTX-3.3 is a highly refined and advanced voltage regulator from Texas Instruments, a renowned global semiconductor company.

  • Output Voltage: 3.3 volts
  • Current: up to 800mA
  • Dropout Voltage: 1.2V @ maximum output
  • Feature: protection features
  • Capabilities: built-in current limiting and thermal shutdown
  • Package: TO-252 (3) package
  • Compatibility: compatible with a wide range of capacitors, including low ESR ceramic capacitors
  • Precision: high precision output voltage
