The LM27313XQMFX/NOPB is a high-performance, step-up DC/DC converter designed and manufactured by Texas Instruments. This compact, integrated circuit is engineered to deliver efficient power conversion for a variety of applications, particularly suitable for portable devices due to its small footprint and power-saving features.

Key Features

• High Frequency Operation: With a switching frequency of 1.6 MHz, the LM27313XQMFX/NOPB allows for the use of small, low-profile inductors and capacitors, reducing the overall size of the power supply design.
• Adjustable Output Voltage: The output voltage is adjustable, enabling customization for specific application requirements, and can provide a wide range of output voltages.
• High Efficiency: It offers high efficiency due to its low quiescent current and the use of synchronous rectification.
• Integrated Features: The device includes an internal switch and diode, which simplifies the design and reduces external component count.
• Thermal Shutdown: Enhanced safety features include thermal shutdown, which protects the device from damage due to overheating.

Applications

The LM27313XQMFX/NOPB is versatile and can be used in a broad array of applications, including but not limited to:

• Battery-powered devices
• Handheld instruments
• Portable media players
• Wireless modems
• LED lighting drivers

Quality and Reliability

Texas Instruments is renowned for its commitment to quality and reliability, and the LM27313XQMFX/NOPB is no exception. This product is available in a lead-free, 5-pin SOT-23 package and is characterized for operation from -40°C to 125°C, ensuring performance across a wide range of environmental conditions.

Ordering Information

The part number LM27313XQMFX/NOPB is the specific identifier for this Texas Instruments product, where 'NOPB' denotes that the product is offered in a lead-free package. To place an order or to obtain more detailed information, customers can visit the Texas Instruments website or contact an authorized distributor.
