LM2941SX/NOPB Real Image LM2941SX/NOPB Real Image1 LM2941SX/NOPB Real Image2 LM2941SX/NOPB Real Image3
Same model may have multiple batches, images only for reference.
LM2941SX/NOPB Real Image LM2941SX/NOPB Real Image1 LM2941SX/NOPB Real Image2 LM2941SX/NOPB Real Image3
LM2941SX/NOPB Real Image LM2941SX/NOPB Real Image1 LM2941SX/NOPB Real Image2 LM2941SX/NOPB Real Image3
Same model may have multiple batches, images only for reference.

LM2941SX/NOPB

Part No LM2941SX/NOPB
Manufacturer Texas Instruments
Catalog PMIC - Voltage Regulators - Linear
Description IC REG LDO ADJ 1A DDPAK
Datasheet
LM2941SX/NOPB Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Output Type Adjustable
Number of Regulators 1
Maximum Input Voltage 26V
Nominal Output Voltage (Min/Fixed) 5V
Maximum Output Voltage 20V
Dropout Voltage-Max 1V @ 1A
Output Current 1A
Operating Supply Current 10mA to 15mA
Control Features Enable
Protection Features Over Temperature, Reverse Polarity, Short Circuit
Temperature Range - Operating -40°C to 125°C
Regulator Topology Positive Adjustable
Output Voltage 5 V to 20 V
Voltage - Dropout (Typical) 0.5V @ 1A
Mounting SMD (SMT)
Case / Package DDPAK/TO-263-5
Win Source Part Number 019010-LM2941SX/NOPB
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Application Field Used in Automotive, Industrial
Ultra Librarian 3D Model Ultra Librarian LM2941SX/NOPB CAD Model

Description

The LM2941SX/NOPB from Texas Instruments is a high-performance, low-dropout voltage regulator that offers a robust and versatile solution for a wide range of applications.

  • Adjustable Output Voltage: Can be set from 5V to 15V
  • Output Current: Up to 1A
  • Dropout Voltage: Just 0.5V
