LM317MDT/NOPB Real Image LM317MDT/NOPB Real Image
Same model may have multiple batches, images only for reference.
LM317MDT/NOPB Real Image LM317MDT/NOPB Real Image
LM317MDT/NOPB Real Image LM317MDT/NOPB Real Image
Same model may have multiple batches, images only for reference.

LM317MDT/NOPB

Part No LM317MDT/NOPB
Manufacturer Texas Instruments
Catalog PMIC - Voltage Regulators - Linear
Description IC REG LINEAR ADJ 0.5A TO252-3
Datasheet
LM317MDT/NOPB Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Tube/Rail
Status Active
Output Type Adjustable
Number of Regulators 1
Maximum Input Voltage 37V
Nominal Output Voltage (Min/Fixed) 1.25V
Maximum Output Voltage 37V
Output Current 500mA
PSRR 80dB to 65dB (120Hz)
Control Protection Features Over Current, Over Temperature, Short Circuit
Temperature Range - Operating 0°C to 125°C
Regulator Topology Positive Adjustable
Output Voltage 1.25 V to 37 V
Mounting SMD (SMT)
Case / Package TO-252-3
Win Source Part Number 206343-LM317MDT/NOPB
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian LM317MDT/NOPB CAD Model

Description

The LM317MDT/NOPB from Texas Instruments is a highly versatile and reliable adjustable voltage regulator that offers outstanding performance and durability.

  • Load Current: More than 1.5A
  • Output Voltage: Adjustable over a 1.2 to 37V range
  • Current Limiting: Yes
  • Thermal Shutdown: Yes
  • Safe Area Compensation: Yes
  • Reference Voltage Tolerance: 2%
  • Temperature Range: -40 to 125 degrees Celsius
  • Compliance: RoHS compliant
  • Package: TO-252 (D Pak)
