The LM320K-15 is a robust negative voltage regulator designed and manufactured by Texas Instruments, a global leader in semiconductor solutions. This particular model is part of the LM320 series, which is well-known for providing reliable and stable negative voltage outputs. The LM320K-15 is specifically engineered to deliver a fixed output voltage of -15V, which is essential for a wide range of electronic applications.

Key Features

• Fixed Output Voltage: The LM320K-15 offers a constant output of -15V, which is crucial for circuits requiring a stable negative voltage supply.
• High Current Output: Capable of delivering up to 1.5A of output current, this regulator can support applications that demand higher current levels.
• Thermal Overload Protection: The device includes built-in thermal overload protection that safeguards it from damage due to excessive heat and operational stress.
• Short Circuit Protection: Enhanced safety is provided through the short circuit protection feature, ensuring the regulator and your circuitry are protected from potential short-circuiting events.
• Safe Operating Area Protection: This function protects the regulator against immediate destruction under extreme operating conditions, making it more durable and reliable.
• Rugged Design: The LM320K-15 is encapsulated in a TO-3 package, known for its high power dissipation and durability, making it suitable for demanding environments.

Applications

The LM320K-15 is versatile and can be used in a variety of applications, including:

• Power supplies for operational amplifiers and other analog devices
• Digital circuits requiring a stable negative reference voltage
• Automotive applications where negative voltage is needed
• Instrumentation and laboratory equipment
• Industrial control systems

Conclusion

The LM320K-15 from Texas Instruments is an exemplary solution for systems requiring a reliable negative voltage regulator. Its robust design, coupled with essential protection features, ensures stable performance and longevity in a range of applications. Whether for industrial, automotive, or consumer electronics, the LM320K-15 is a dependable choice for negative voltage regulation needs.
