LM3224MM-ADJ/NOPB Real Image LM3224MM-ADJ/NOPB Real Image
Same model may have multiple batches, images only for reference.
LM3224MM-ADJ/NOPB Real Image LM3224MM-ADJ/NOPB Real Image
LM3224MM-ADJ/NOPB Real Image LM3224MM-ADJ/NOPB Real Image
Same model may have multiple batches, images only for reference.

LM3224MM-ADJ/NOPB

Part No LM3224MM-ADJ/NOPB
Manufacturer Texas Instruments
Catalog PMIC - Voltage Regulators - DC DC Switching Regulators
Description IC REG BOOST ADJ 1.9A 8VSSOP
Datasheet
LM3224MM-ADJ/NOPB Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Purpose Step-Up
Topology Boost
Output Type Adjustable
Number of Outputs 1
Minimum Input Voltage 2.7V
Maximum Input Voltage 7V
Nominal Output Voltage (Min/Fixed) 1.26V
Maximum Output Voltage 20V
Output Current 1.9A (Switch)
Frequency - Switching 615kHz, 1.25MHz
Synchronous Rectifier No
Temperature Range - Operating -40°C to 125°C (TJ)
Mounting SMD (SMT)
Case / Package 8-VSSOP
Win Source Part Number 298761-LM3224MM-ADJ
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Application Field Used in Portable Devices, Consumer Electronics
Ultra Librarian 3D Model Ultra Librarian LM3224MM-ADJ/NOPB CAD Model

Description

The LM3224MM-ADJ/NOPB is a high-performance, advanced power management device from Texas Instruments.

  • Type: Step-up DC/DC converter
  • Input Voltage Range: 2.7V to 5.5V
  • Output Voltage (Adjustable): 3.3V to 11V
  • Output Current: Up to 2A
  • Frequency: 2-MHz fixed-frequency PWM
  • Features: Under-voltage lockout (UVLO), thermal shutdown, current limit, short-circuit protection
  • Feature: Soft-start
  • Feature: Shutdown mode (supply current less than 1µA)
  • Package: 8-pin VSSOP
  • Compliance: RoHS compliant, free from lead, bromine, and antimony
