The LM5002MAX is a high-voltage switch mode regulator that is part of Texas Instruments' innovative power management solutions. This versatile device is capable of handling input voltages from 3V to 75V, which makes it exceptionally well-suited for a wide range of applications, including industrial, automotive, and telecommunications systems.

The LM5002MAX features an adjustable output voltage that can be set from 1.225V to 50V, providing the flexibility needed to power various circuits and components. With its ability to deliver up to 2A of continuous output current, this regulator can meet the demands of high-performance electronics.

Key Features

• Wide Input Voltage Range: Operates from 3V to 75V, accommodating the fluctuations commonly found in industrial environments.
• Adjustable Output Voltage: Output can be set from 1.225V to 50V to power a diverse set of devices.
• High Output Current: Capable of delivering up to 2A, making it suitable for heavy-duty applications.
• Efficiency: Integrated features such as an adjustable switching frequency (up to 1MHz) and a low standby current optimize the efficiency of the device.
• Protection: Offers built-in thermal shutdown, current limit protection, and an under-voltage lockout to ensure the safety and reliability of your system.
• Package: Available in a thermally enhanced 16-pin HTSSOP package that ensures proper heat dissipation for reliable operation under varying conditions.

Applications

The LM5002MAX's robust design and versatile capabilities make it an ideal choice for a variety of applications. It can be used in power conditioning, distributed power systems, pre-regulation for linear regulators, and as a step-down or inverting converter. Its high-voltage capability also makes it perfect for automotive applications such as infotainment systems, GPS, and audio systems, as well as for industrial applications, including factory automation and control systems.

With the LM5002MAX, Texas Instruments continues its commitment to providing high-quality, reliable power management solutions that meet the evolving needs of modern electronics.
