The LM5113TME/NOPB is a state-of-the-art half-bridge gate driver designed and manufactured by Texas Instruments, a leader in semiconductor solutions. This driver is specifically engineered to efficiently control the power levels of GaN and MOSFET transistors in various applications. It is a critical component for modern power conversion and management systems, offering high efficiency and reliability.

Key Features:

• Voltage Range: The LM5113TME/NOPB operates over a wide range of voltages, typically from 5V to 14V, making it versatile for different power systems.
• Drive Capability: The device provides a robust gate drive with peak output currents of up to 1.2A for the high-side and 2A for the low-side, ensuring swift and efficient switching.
• Protection: Built-in under-voltage lockout (UVLO) for both high-side and low-side ensures that the device operates only when sufficient supply voltage is present, protecting the system from potential damage.
• Propagation Delay: The LM5113TME/NOPB boasts a low propagation delay, typically 25 ns, which minimizes transition losses and improves overall system performance.
• Drive Configuration: The half-bridge configuration allows for independent high-side and low-side gate driver outputs, providing design flexibility.
• Temperature Range: With an operating temperature range of -40°C to 125°C, this gate driver can perform reliably in a wide range of environmental conditions.

Applications:

The LM5113TME/NOPB is ideal for various high-performance applications, including:

• DC/DC Converters
• Synchronous Buck Converters
• Class-D Audio Amplifiers
• Motor Drives
• Power Inverters

Package and Quality:

The device comes in an 8-pin WSON package, which is compact and suitable for space-constrained applications. It is also provided in a lead-free, RoHS-compliant package, reflecting Texas Instruments' commitment to environmental sustainability. Moreover, the NOPB designation indicates that this product is provided without lead (Pb) in the packaging, ensuring compliance with global regulations on hazardous substances.

The LM5113TME/NOPB is a testament to Texas Instruments' dedication to providing high-quality, efficient, and reliable solutions for the ever-evolving demands of power electronics.
