LMR23615DRRT - Texas Instruments Step-Down Converter

The LMR23615DRRT is a highly efficient, synchronous, step-down DC/DC converter from Texas Instruments, designed to deliver a continuous output current of up to 1.5 A. This compact power management integrated circuit is ideal for a wide range of applications, including industrial, automotive, and consumer electronics where power efficiency and space constraints are critical considerations.

Key Features

• Wide Input Voltage Range: Capable of operating from an input voltage range of 3.5 V to 36 V, the LMR23615DRRT is versatile and can be used in systems with varying supply voltages.
• Adjustable Output Voltage: Users can set the output voltage from 0.8 V to 30 V, allowing for flexibility in design and compatibility with a variety of downstream components.
• High Efficiency: The device offers high efficiency due to its synchronous step-down regulator topology, which reduces the need for external diodes and helps minimize power losses.
• Thermal and Overcurrent Protection: Built-in thermal shutdown and overcurrent protection features safeguard the device and the system from damage due to overheating or excessive load conditions.
• Small Footprint: Housed in a small 3.5 mm x 3.5 mm VQFN (RRT) package, the LMR23615DRRT is designed for space-constrained applications.

Applications

The LMR23615DRRT is well-suited for a variety of applications, including:

• Industrial and Automation Systems
• Automotive Infotainment and Telematics
• Power Supplies for FPGAs, DSPs, and Microcontrollers
• Portable and Battery-Powered Equipment

Ordering and Packaging Information

The Texas Instruments LMR23615DRRT is available in a highly thermal-efficient 11-pin VQFN package and can be ordered with a custom reel size for automated assembly processes. For detailed specifications, technical documentation, and ordering information, please visit the Texas Instruments website or contact an authorized distributor.
