LMV431AIM5

Part No LMV431AIM5
Manufacturer Texas Instruments
Catalog PMIC - Voltage Reference
Description Low-Voltage (1.24V) Adjustable Precision Shunt Regulators | IC VREF SHUNT ADJ SOT23-5
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel
Reference Type Shunt
Output Type Adjustable
Min/Fixed Output Voltage 1.24V
Maximum Output Voltage 30V
Output Current 15mA
Tolerance ±1%
Current - Cathode 80μA
Temperature Range - Operating -40°C ~ 85°C
Mounting Style SMD
Manufacturer Package SC-74A, SOT-753
Supplier Device Package SOT-23-5
Family Part Number LMV431
Manufacturer Pack Quantity 1
MSL Level 1 (Unlimited)
Win Source Part Number 1202143-LMV431AIM5
Manufacturer Homepage www.ti.com
Popularity Medium
Supply and Demand Status Balance
Application Field Used in Power Management
Ultra Librarian 3D Model Ultra Librarian LMV431AIM5 CAD Model

Description

The LMV431AIM5 from Texas Instruments is a precision low-voltage shunt regulator that has been designed to meet the requirements of modern electronic applications. This device is part of the LMV431 series and is available in the SOT-23-5 package, making it ideal for space-constrained applications.

Key Features

  • Adjustable Output Voltage: This regulator offers an adjustable output voltage from 1.24V to 30V, providing flexibility across a wide range of applications.
  • Low Dynamic Output Impedance: With a dynamic output impedance of 0.2 ohms, the LMV431AIM5 ensures stable load regulation, which is critical for maintaining consistent performance.
  • Low Threshold Voltage: The low threshold voltage of 1.24V allows for low voltage operation, making it suitable for battery-operated devices.
  • High Precision: The device features a typical temperature stability of only 50 ppm/°C, ensuring reliable operation over a wide temperature range.
  • Fast Turn-on Response: The LMV431AIM5 has a fast turn-on response time, which is crucial for applications that require quick power-up sequences.

Applications

The LMV431AIM5 is versatile and can be used in a variety of applications, including:

  • Adjustable Voltage and Current References
  • Power Supplies
  • Battery Chargers
  • Switching Power Supplies
  • Portable Electronics
  • Automotive Electronics

Quality and Reliability

Texas Instruments is known for its commitment to quality and reliability. The LMV431AIM5 is no exception, as it is designed to meet the stringent requirements of industrial and automotive standards. Its robust design ensures long-term reliability, making it a preferred choice for engineers and designers looking for a dependable voltage reference solution.

Conclusion

With its adjustable output voltage, low dynamic output impedance, and high precision, the LMV431AIM5 from Texas Instruments is a highly reliable shunt regulator that can cater to a broad spectrum of voltage regulation needs across various industries. Its small form factor and robustness make it an excellent choice for both portable and fixed electronic applications.
