LMZ14203EXTTZX/NOPB

Part No LMZ14203EXTTZX/NOPB
Manufacturer Texas Instruments
Catalog Power Supplies Board Mount DCDC Converters
Description IC BUCK SYNC ADJ 3A TO-PMOD-7 / Module DC-DC 1-OUT 0.8V to 6V 3A 18W 7-Pin TO-PMOD EP T/R
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Power Supplies - Board Mount
Manufacturer Texas Instruments
Series SIMPLE SWITCHER
Packaging Reel package
Type Non-Isolated PoL Module
Number of Outputs 1
Input Voltage MIN 6V
Voltage Input MAX 42V
Voltage - Output 1 0.8 ~ 6 V
Current - Output (Maximum) 3A
Applications ITE (Commercial)
Features OTP, OVP, SCP, UVLO
Operating Temperature Range -55°C ~ 125°C
Efficiency 90%
Mounting SMD
Package TO-PMOD-7, Power Module
Dimension 0.40" L x 0.39" W x 0.18" H (10.2mm x 9.9mm x 4.6mm)
Win Source Part Number 779621-LMZ14203EXTTZX/NOPB
Popularity Medium
Supply and Demand Status Limited
Family Name LMZ14203EXT
Introduction Date June 19, 2010
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2031
Ultra Librarian 3D Model Ultra Librarian LMZ14203EXTTZX/NOPB CAD Model

Description

The LMZ14203EXTTZX/NOPB is a highly efficient, robust power module designed and manufactured by Texas Instruments. This advanced power solution is part of the SIMPLE SWITCHER® series, which is renowned for its ease of use and reliable performance. The module is specifically engineered to meet the needs of a wide range of applications, including telecommunications, industrial systems, and consumer electronics.

Key Features

  • Output Voltage Range: The LMZ14203EXTTZX/NOPB provides an adjustable output voltage range from 0.8V to 6V, catering to a variety of power requirements for different devices.
  • High Efficiency: With an efficiency rate of up to 92%, this power module ensures minimal energy loss during operation, making it ideal for energy-sensitive applications.
  • Input Voltage: The device supports an input voltage range from 6V to 42V, making it versatile for use with various input sources.
  • Current Capacity: It is capable of delivering up to 3A of output current, providing sufficient power for a range of electronic components.
  • Thermal Performance: The LMZ14203EXTTZX/NOPB is designed with excellent thermal performance in mind, featuring an extended temperature range that ensures stability across different operating conditions.

Advanced Protection Features

The power module incorporates several protection features to ensure the longevity and reliability of both the module and the end application. These include:

  • Over-temperature protection
  • Under-voltage lockout
  • Over-current protection
  • Short-circuit protection

Easy Integration

Designed with practicality in mind, the LMZ14203EXTTZX/NOPB comes in a compact, surface-mount package that simplifies the integration process. Its pinout is optimized for easy placement and routing on printed circuit boards, making it a user-friendly choice for designers and engineers.

Quality and Reliability

Texas Instruments is known for its commitment to quality, and the LMZ14203EXTTZX/NOPB is no exception. It is RoHS compliant and lead-free, ensuring it meets environmental standards and global regulatory requirements. The device's robust construction and comprehensive testing guarantee performance you can trust in your critical applications.
