The LMZ22005TZX/NOPB is a high-performance, easy-to-use power module from Texas Instruments, designed to meet the needs of a wide range of applications. This power solution integrates a DC/DC converter, inductor, and passives into a compact, low-profile package. Its innovative design simplifies the implementation of power supply circuits, reducing design time and accelerating product development.

Key Features

• Output Voltage Range: The module offers an adjustable output voltage range from 0.8V to 5V, allowing for flexibility in various applications.
• High Efficiency: With an efficiency of up to 95%, this power module ensures minimal power loss and heat generation, making it suitable for thermally sensitive applications.
• Load Current: It can deliver up to 5A of output current, catering to applications with high power demands.
• Input Voltage Range: The wide input voltage range of 6V to 20V allows the LMZ22005TZX/NOPB to operate in various supply environments.
• Integrated Shielding: The module features integrated shielding to reduce electromagnetic interference (EMI), ensuring compliance with regulatory standards and improving system reliability.
• Thermal Performance: Excellent thermal performance is achieved through an innovative package design, allowing for operation in high-temperature environments without the need for additional heat sinking.

Applications

The LMZ22005TZX/NOPB is versatile and can be used in a variety of applications, including but not limited to:

• Telecommunications equipment
• Networking equipment such as routers and switches
• Industrial systems
• Test equipment
• FPGA, DSP, and ASIC power supplies

Quality and Reliability

Texas Instruments is known for its commitment to quality, and the LMZ22005TZX/NOPB is no exception. It is designed to meet the stringent requirements of industrial and commercial applications. The module is RoHS compliant and is delivered in a lead-free, surface-mount package, ensuring it meets current environmental standards for electronic components.
