LMZ34202RVQR

Part No LMZ34202RVQR
Manufacturer Texas Instruments
Catalog Power Supplies Board Mount DCDC Converters
Description SIMPLE SWITCHER, 4.5V TO 42V, 2 / Module DC-DC 1-OUT 2.5V to 7.5V 2A 43-Pin B3QFN T/R
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Power Supplies - Board Mount
Manufacturer Texas Instruments
Series SIMPLE SWITCHER
Packaging Reel package
Type Non-Isolated PoL Module
Number of Outputs 1
Input Voltage MIN 4.5V
Voltage Input MAX 42V
Voltage - Output 1 2.5 ~ 7.5 V
Current - Output (Maximum) 2A
Applications ITE (Commercial)
Features Remote On/Off, OCP, OTP, UVLO
Operating Temperature Range -40°C ~ 105°C
Efficiency 92%
Mounting SMD
Package 43-BQFN Module
Dimension 0.39" L x 0.39" W x 0.17" H (10.0mm x 10.0mm x 4.3mm)
Manufacturer Package 43-B3QFN (10x10)
Win Source Part Number 779633-LMZ34202RVQR
Popularity Medium
Supply and Demand Status Limited
Family Name LMZ34202RVQR
Introduction Date March 09, 2017
ECCN EAR99
Country of Origin Philippines
Halogen Free Compliant
Estimated EOL Date 2031
Ultra Librarian 3D Model Ultra Librarian LMZ34202RVQR CAD Model

Description

Overview of Texas Instruments LMZ34202RVQR

The Texas Instruments LMZ34202RVQR is a high-performance, easy-to-use power solution that integrates the inductor and passives onto a single device. This power module is designed to simplify the power supply design process, offering a compact, reliable, and efficient solution for a wide range of applications.

Key Features

  • Integrated Power Solution: The LMZ34202RVQR integrates an inductor and passives into a low-profile QFN package, reducing design complexity and saving board space.
  • Wide Input Voltage Range: It operates from an input voltage range of 4.5V to 42V, making it suitable for various applications, including industrial, automotive, and communications equipment.
  • High Efficiency: This module offers high efficiency and excellent thermal performance, which is critical for maintaining system reliability and performance.
  • Adjustable Output Voltage: The output voltage is adjustable from 0.8V to 6V, providing flexibility to power a broad range of devices and ICs.
  • Protection Features: It includes over-temperature and over-current protection, enhancing the safety and durability of the end application.

Applications

The LMZ34202RVQR is ideal for use in various applications, including but not limited to:

  • Telecommunications infrastructure
  • Industrial controls and automation
  • Automotive infotainment and telematics
  • Point-of-load conversions

Technical Specifications

Here are some of the technical specifications of the LMZ34202RVQR:

  • Output Current: Capable of delivering up to 2A of continuous output current.
  • Switching Frequency: It has a programmable switching frequency ranging from 200kHz to 1MHz, allowing designers to optimize performance for their specific application.
  • Package: The device comes in a compact 41-pin QFN package with a size of 9mm x 7mm x 4mm.

With its robust feature set, the LMZ34202RVQR from Texas Instruments is a powerful, versatile power module that streamlines the design process for engineers and ensures stable, efficient operation for a diverse array of electronic products.
