LP2951DR Real Image LP2951DR real image1879 LP2951DR real image1880 LP2951DR Real Image1 LP2951DR Real Image2
Same model may have multiple batches, images only for reference.
LP2951DR Real Image LP2951DR real image1879 LP2951DR real image1880 LP2951DR Real Image1 LP2951DR Real Image2
LP2951DR Real Image LP2951DR real image1879 LP2951DR real image1880 LP2951DR Real Image1 LP2951DR Real Image2
Same model may have multiple batches, images only for reference.

LP2951DR

Part No LP2951DR
Manufacturer Texas Instruments
Catalog PMIC - Voltage Regulators - Linear
Description IC REG LDO 5V/ADJ 0.1A 8SOIC
Datasheet
LP2951DR Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Output Type Adjustable (Fixed)
Number of Regulators 1
Maximum Input Voltage 30V
Nominal Output Voltage (Min/Fixed) 1.235V (5V)
Maximum Output Voltage 30V
Dropout Voltage-Max 0.6V @ 100mA
Output Current 100mA
Operating Supply Current 120μA to 14mA
Control Features Enable
Protection Features Over Current, Over Temperature, Short Circuit
Temperature Range - Operating -40°C to 125°C
Regulator Topology Positive Fixed or Adjustable
Output Voltage 5V, 1.235 V to 30 V
Voltage - Dropout (Typical) 0.38V @ 100mA
Mounting SMD (SMT)
Case / Package 8-SOIC
Win Source Part Number 120544-LP2951DR
Family Name LP2951
Introduction Date August 01, 2003
ECCN EAR99
Country of Origin Mexico
Halogen Free Compliant
Estimated EOL Date 2027
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian LP2951DR CAD Model

Description

The LP2951DR is a high-quality, adjustable micro-power voltage regulator from Texas Instruments, a leading technology company known for its semiconductor solutions. It is designed to deliver up to 100 mA output current with an adjustable output voltage range of 1.24V to 29V.

  • Key Features: Low quiescent current of 75 µA, wide temperature range (-40°C to 125°C), thermal shutdown, and current limiting features, error flag output for low output voltage warnings.
  • Package: 8-pin SOIC
  • Applications: Battery-powered devices, portable instruments, and cordless phones.
