LT1013DDR

Part No LT1013DDR
Manufacturer Texas Instruments
Catalog Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description IC OPAMP GP 1MHZ 8SOIC
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Amplifier Type General Purpose
Number of Circuits 2
Slew Rate 0.4 V/μs
Gain Bandwidth Product (GBP) 1MHz
Current - Input Bias 15nA
Voltage - Input Offset 200μV
Operating Supply Current 350μA
Supply Voltage - Operating 4 V to 44 V, ±2 V to 22 V
Temperature Range - Operating 0°C to 70°C
Mounting SMD (SMT)
Case / Package 8-SOIC
Win Source Part Number 020192-LT1013DDR
Family Name LT1013D
Introduction Date August 01, 2003
ECCN EAR99
Country of Origin Mexico
Halogen Free Compliant
Estimated EOL Date 2027
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Industrial
Ultra Librarian 3D Model Ultra Librarian LT1013DDR CAD Model

Description

The LT1013DDR is an exceptional product from Texas Instruments, a global semiconductor design and manufacturing company. This high-quality, precision dual operational amplifier (op amp) is designed to cater to a wide array of applications, such as precision active filters and instrumentation, and is an ideal choice for those seeking a combination of precision, low power, and excellent value in a dual operational amplifier.

  • Low Offset Voltage: 50µV
  • Low Input Bias Current: 20nA
  • Wide Gain Bandwidth: 1.1MHz
  • Low Power Consumption: Suitable for battery-powered devices and portable equipment
  • Wide Supply Range: 2V to 36V
  • Operating Temperature Range: -40°C to +125°C
  • Package: 8-pin SOIC
  • Features: ESD protection, short-circuit protection
  • Compliance: RoHS compliant

The LT1013DDR is a high-performance, precision dual operational amplifier that offers a combination of accuracy, low power consumption, and wide operating range, suitable for accurate signal amplification, power-sensitive applications, and a wide range of operating conditions.
