The Texas Instruments MSP430F47187IPZ is a highly integrated, high-performance microcontroller designed for metering and industrial applications. It is part of the MSP430 family, which is renowned for its low power consumption and versatile features set. This microcontroller is particularly suitable for applications requiring complex algorithms and multiple sensor interfaces due to its rich set of peripherals and its robust processing capabilities.

Key Features

• Core: 16-bit RISC architecture, MSP430 CPU
• Frequency: Up to 16 MHz
• Flash Memory: 120KB, allowing for ample program storage
• RAM: 8KB, providing sufficient space for data handling
• Digital I/O Pins: Multiple digital I/O pins for versatile control and interfacing options
• Analog-to-Digital Converter (ADC): Integrated high-resolution ADC for precise sensor readings and data acquisition
• Communication Peripherals: Includes I2C, SPI, and UART for easy connectivity with other devices and components
• Power Management: Advanced power management features for ultra-low-power operation, ideal for battery-powered applications
• Temperature Range: Industrial-grade temperature range ensuring reliability in harsh conditions
• Package: 100-pin LQFP (Low-profile Quad Flat Package) for a compact footprint

Applications

The MSP430F47187IPZ microcontroller is designed to meet the demands of a wide range of applications, including but not limited to:

• Smart Metering (Electricity, Gas, Water)
• Industrial Control Systems
• Building Automation
• Portable and Low-power Devices
• Energy Harvesting Applications

Design Support

Developers can take advantage of Texas Instruments' comprehensive design support ecosystem, which includes development tools, reference designs, and online resources to accelerate the design and implementation process. The MSP430F47187IPZ is supported by the MSP430 software development environment, which features an integrated development environment (IDE), compilers, and debugging tools to streamline development.
