PTH04T241WAD

Name: PTH04T241WAD
Brand: Texas Instruments
SKU: 283809
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	PTH04T241WAD
Manufacturer	Texas Instruments
Catalog	Power Supplies Board Mount DCDC Converters
Description	Module DC-DC 1-OUT 0.69V to 3.6V 10A 11-Pin DIP Module Tray / MODULE PIP 10A 2.2/5.5V 11-DIP
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Manufacturer	Texas Instruments
Standard Package	49
Category	Power Supplies - Board Mount
Family	DC DC Converters
Series	PTH04T241W
Packaging	Tray
Type	Non-Isolated PoL Module
Number of Outputs	1
Voltage - Input (Min)	2.2V
Voltage - Input (Max)	5.5V
Voltage - Output 1	0.69 ~ 3.6 V
Current - Output (Max)	10A
Applications	ITE (Commercial)
Mounting Style	Through Hole
Package	11-DIP Module
Size / Dimension	0.87" L x 0.62" W x 0.33" H (22.1mm x 15.7mm x 8.4mm)
Operating Temperature Range	-40°C ~ 85°C
Efficiency	94%
Power (Watts) - Max	36W
Catalog	PTH04T241W
Win Source Part Number	081182-PTH04T241WAD
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Limited
Family Name	PTH04T241W
Introduction Date	December 01, 2006
ECCN	EAR99
Country of Origin	United States of America
Halogen Free	Not Compliant
Estimated EOL Date	2031
Ultra Librarian 3D Model	Ultra Librarian PTH04T241WAD CAD Model

Alternative Products

Description

The PTH04T241WAD from Texas Instruments is a high-performance, 10A rated, non-isolated power module that is part of the PTH series.

Input Voltage Range: 4.5V to 14V
Adjustable Output Voltage: 0.6V to 5.5V
Auto-Track Sequencing: Yes
Efficiency: Up to 96% @ half load
Over-Temperature Protection: Yes
Output Over-Current Protection: Yes
Input Under-Voltage Lockout: Yes
