PTN78060HAH Real Image PTN78060HAH Real Image
Same model may have multiple batches, images only for reference.
PTN78060HAH Real Image PTN78060HAH Real Image
PTN78060HAH Real Image PTN78060HAH Real Image
Same model may have multiple batches, images only for reference.

PTN78060HAH

Part No PTN78060HAH
Manufacturer Texas Instruments
Catalog Power Supplies Board Mount DCDC Converters
Description REG SW 11.85-22V 3A HORZ T/H
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer Texas Instruments
Standard Package 36
Category Power Supplies - Board Mount
Family DC DC Converters
Series PTN78060H
Packaging Tray
Type Non-Isolated PoL Module
Number of Outputs 1
Voltage - Input (Min) 15V
Voltage - Input (Max) 36V
Voltage - Output 1 11.85 ~ 22 V
Current - Output (Max) 3A
Applications ITE (Commercial)
Features With UVLO
Mounting Style Through Hole
Package 7-DIP Module
Size / Dimension 1.00" L x 0.62" W x 0.35" H (25.4mm x 15.7mm x 8.9mm)
Operating Temperature Range -40°C ~ 85°C
Efficiency 96%
Power (Watts) - Max 45W
Catalog PTN78060H Series
Win Source Part Number 081185-PTN78060HAH
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Application Field Used in Power Management, HVAC, Test & Measurement, Medical, Automotive, Avionics
Ultra Librarian 3D Model Ultra Librarian PTN78060HAH CAD Model

Description

The PTN78060HAH from Texas Instruments is a highly innovative, high-performance product that is designed to offer a wide range of solutions for various applications.

  • Type: High-efficiency, 3-A, 15-W rated power module, non-isolated adjustable output voltage regulator
  • Supply Voltage: Up to 36V
  • Maximum Input Voltage: 36V
  • Output Voltage: Adjustable from 2.5V to 12.6V
  • Efficiency: Up to 96%
  • Safety Features: On/off inhibit, over-temperature protection, and output current limit
  • Package: Compact, easy-to-mount, vertical plug-in module package
