SN65HVD230DRG4 Real Image SN65HVD230DRG4 real image SN65HVD230DRG4 label picture SN65HVD230DRG4 Real Image1 SN65HVD230DRG4 Real Image2
Same model may have multiple batches, images only for reference.
SN65HVD230DRG4 Real Image SN65HVD230DRG4 real image SN65HVD230DRG4 label picture SN65HVD230DRG4 Real Image1 SN65HVD230DRG4 Real Image2
SN65HVD230DRG4 Real Image SN65HVD230DRG4 real image SN65HVD230DRG4 label picture SN65HVD230DRG4 Real Image1 SN65HVD230DRG4 Real Image2
Same model may have multiple batches, images only for reference.

SN65HVD230DRG4

Part No SN65HVD230DRG4
Manufacturer Texas Instruments
Catalog Interface - Drivers, Receivers, Transceivers
Description IC CAN TRANSCEIVER 3.3V 8-SOIC
Datasheet
SN65HVD230DRG4 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Type Transceiver
Protocol CAN
Number of Drivers/Receivers 1/1
Duplex Half
Receiver Hysteresis 100mV
Data Rate 1Mbps
Supply Voltage - Operating 3 V to 3.6 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 8-SOIC
Win Source Part Number 029532-SN65HVD230DRG4
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian SN65HVD230DRG4 CAD Model

Description

The SN65HVD230DRG4 by Texas Instruments is a robust, high-performance device designed to provide superior communication capabilities for a variety of applications.

  • Operating Temperatures: -40 to 125 degrees Celsius
  • Supply Voltage Range: 3.0 to 3.6 V
  • Standby Current Consumption: 370 µA
  • Function: Dominant time-out
  • Data Rates: Up to 1 Mbps
  • Standard: ISO 11898-2 physical layer
  • Bus Nodes: Up to 120
  • Receiver: Fail-safe
  • Package: 8-pin SOIC
  • Protection: Thermal shutdown
