SN74AHC00D Real Image SN74AHC00D Real Image
Same model may have multiple batches, images only for reference.
SN74AHC00D Real Image SN74AHC00D Real Image
SN74AHC00D Real Image SN74AHC00D Real Image
Same model may have multiple batches, images only for reference.

SN74AHC00D

Part No SN74AHC00D
Manufacturer Texas Instruments
Catalog Logic - Gates and Inverters
Description IC GATE NAND 4CH 2-INP 14-SOIC
Datasheet
SN74AHC00D Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Logic Type NAND Gate
Number of Circuits 4
Number of Inputs 2
Supply Voltage - Operating 2 V to 5.5 V
Current - Quiescent (Max) 2μA
Current - Output High, Low 8mA, 8mA
Logic Level - Low 0.5 V to 1.65 V
Logic Level - High 1.5 V to 3.85 V
Max Propagation Delay @ V, Max CL 7.5ns @ 5V, 50pF
Temperature Range - Operating -40°C to 125°C
Mounting SMD (SMT)
Case / Package 14-SOIC
Dimension 14-SOIC (0.154", 3.90mm Width)
Win Source Part Number 104230-SN74AHC00D
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian SN74AHC00D CAD Model

Description

The SN74AHC00D is a high-quality, advanced product from Texas Instruments, a renowned and trusted brand in the electronics industry.

  • Type: Quadruple 2-input positive-NAND gate.
  • Operating Voltage: 2V to 5.5V.
  • Load Capacity: Drive up to 8 LVTTL loads.
  • Technology: CMOS technology.
  • Package: 14-pin SOIC package.
  • Operating Temperature: -40°C to 85°C.
  • Input Tolerance: Up to 5.5V, regardless of the supply voltage.
  • Feature: High drive capability.
