SN74AHC1G14DBVR Real Image SN74AHC1G14DBVR real image5871 SN74AHC1G14DBVR real image5872 SN74AHC1G14DBVR real image5873
Same model may have multiple batches, images only for reference.
SN74AHC1G14DBVR Real Image SN74AHC1G14DBVR real image5871 SN74AHC1G14DBVR real image5872 SN74AHC1G14DBVR real image5873
SN74AHC1G14DBVR Real Image SN74AHC1G14DBVR real image5871 SN74AHC1G14DBVR real image5872 SN74AHC1G14DBVR real image5873
Same model may have multiple batches, images only for reference.

SN74AHC1G14DBVR

Part No SN74AHC1G14DBVR
Manufacturer Texas Instruments
Catalog Logic - Gates and Inverters
Description IC SCHMITT-TRG INV GATE SOT23-5
Datasheet
SN74AHC1G14DBVR Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Logic Type Inverter
Number of Circuits 1
Number of Inputs 1
Features Schmitt Trigger
Supply Voltage - Operating 2 V to 5.5 V
Current - Quiescent (Max) 1μA
Current - Output High, Low 8mA, 8mA
Logic Level - Low 0.9 V to 1.65 V
Logic Level - High 2.2 V to 3.85 V
Max Propagation Delay @ V, Max CL 10.6ns @ 5V, 50pF
Temperature Range - Operating -40°C to 125°C
Mounting SMD (SMT)
Case / Package SOT-23-5
Dimension SC-74A, SOT-753
Win Source Part Number 006549-SN74AHC1G14DBVR
Family Name SN74AHC1G14
Introduction Date February 01, 2010
ECCN EAR99
Country of Origin China, United States of America
Halogen Free Compliant
Estimated EOL Date 2028
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian SN74AHC1G14DBVR CAD Model

Description

The SN74AHC1G14DBVR is a high-performance, single-gate CMOS device from Texas Instruments.

  • Type: Single Schmitt-trigger inverter
  • Voltage Range: 2V to 5.5V
  • Operating Temperature: -40°C to 85°C
  • Package: SOT-23
  • Performance: Fast propagation delay times
  • Power Consumption: Low
  • Noise Immunity: High
  • Compliance: RoHS compliant and lead-free
