The SN74AUP1G125DPWR is a single, low-power buffer gate with a three-state output from Texas Instruments, designed to operate from 0.8 V to 3.6 V. This makes it suitable for a wide range of applications, including those that require power efficiency and battery life extension. The device is part of the advanced ultra-low-power (AUP) family, which is known for its low static and dynamic power consumption.

Key Features

• Power Supply Range: Operates from 0.8 V to 3.6 V, providing design flexibility for various power environments and enabling compatibility with low-voltage microprocessors and microcontrollers.
• Low Power Consumption: Features a low static power consumption of less than 0.9 µA max at 3.6 V, minimizing power waste when the device is inactive, thus prolonging battery life in portable applications.
• High-Speed Operation: With a typical tpd of 3.7 ns at 3.3 V, the device is capable of high-speed operation, making it suitable for high-frequency signal buffering.
• ESD Protection: Offers robust electrostatic discharge (ESD) protection, ensuring device longevity and reliability in environments where ESD events may occur.
• Three-State Output: The three-state output allows the device to be placed in a high-impedance state, effectively disconnecting the output from the circuit, which is useful for bus management and multiplexing applications.

Applications

The SN74AUP1G125DPWR is versatile and can be utilized in a broad range of applications, including:

• Mobile Phones
• PDAs
• Portable Media Players
• Notebook Computers
• Storage Devices
• Logic Level Translation

Package and Quality

The device comes in a small-outline package (SOP), specifically in an 8-pin TSSOP (DPWR) package, which is suitable for space-constrained applications. It is RoHS compliant and supports commercial (0°C to 70°C) and industrial (-40°C to 85°C) temperature ranges, ensuring reliable performance across different operating environments.

With its low power consumption, high-speed operation, and robust protection features, the Texas Instruments SN74AUP1G125DPWR is an excellent choice for designers seeking a reliable, efficient single buffer gate with a three-state output.
