The SN74AUP1G126DPWR is a single bus buffer gate with a 3-state output from Texas Instruments, known for its low-power operation and high-performance capabilities. This particular model comes in a small TSSOP (Thin Shrink Small Outline Package) with 8 pins, designed to save space on printed circuit boards (PCBs) without compromising on functionality.

Key Features

• Low Static-Power Consumption: The device operates with a very low static power consumption (ICC), making it ideal for battery-powered and power-sensitive applications.
• Low Dynamic-Power Consumption: Its dynamic power consumption is also minimized, thanks to the low input capacitance and reduced drive strength.
• Wide Operating Voltage Range: The SN74AUP1G126DPWR is designed to accommodate a broad range of supply voltages, from 0.8V to 3.6V, providing design flexibility for various applications.
• Edge-Rate Control Circuitry: This feature minimizes overshoot and undershoot, thus reducing the noise generated by output transitions.
• Latch-Up Performance: The device exceeds 100 mA per JESD 78, Class II standards, ensuring robust performance against latch-up.
• ESD Protection: Electrostatic discharge protection exceeds JESD 22, ensuring the device's reliability in harsh environments.

Applications

The SN74AUP1G126DPWR is commonly used in a variety of applications due to its versatility and reliability. Some typical applications include:

• Mobile Phones
• PDAs
• Portable Media Players
• Notebooks and Laptops
• Portable Test and Measurement Equipment
• Portable Medical Devices

Technical Specifications

The SN74AUP1G126DPWR is a testament to Texas Instruments' commitment to providing advanced integrated circuit solutions that meet the demands of modern electronic designs. It is a reliable choice for designers looking to integrate a high-performance bus buffer gate with 3-state output into their systems.
