Product Overview: SN74AUP1G79DPWR from Texas Instruments

The SN74AUP1G79DPWR is a high-performance, single positive-edge-triggered D-type flip-flop with a clear input, designed and manufactured by Texas Instruments. This advanced ultra-low power integrated circuit is part of the AUP (Advanced Ultra-low Power) family, which is known for its low power consumption and high-speed operation. The device is particularly suitable for battery-powered applications and portable devices where power efficiency is a critical factor.

Key Features

• Power-Saving Design: The SN74AUP1G79DPWR operates at an ultra-low voltage range of 0.8V to 3.6V, which significantly reduces power consumption and extends battery life in portable applications.
• High-Speed Performance: Despite its low power design, this flip-flop does not compromise on speed, offering typical t<sub>pd of 3.7 ns at 3.3 V, making it suitable for high-speed data processing tasks.
• Single D-Type Flip-Flop: The device contains one D-type flip-flop with a direct clear input, providing precise edge-triggered data storage and release functionality.
• I/O Tolerance: Inputs accept voltages up to 5.5V, allowing for interfacing with higher voltage logic levels without the need for additional level shifters.
• Reduced Crosstalk: Its Schmitt-trigger action at all inputs makes the circuit tolerant to slower input rise and fall times, which reduces crosstalk.
• Compact Packaging: The SN74AUP1G79DPWR comes in a small 8-pin TSSOP (Thin Shrink Small Outline Package) which is ideal for space-constrained applications.

Applications

Thanks to its low power consumption and high-speed operation, the SN74AUP1G79DPWR is well-suited for a variety of applications, including:

• Mobile Phones and Personal Digital Assistants (PDAs)
• Portable Media Players
• Notebook Computers
• Medical Monitoring Devices
• Low-Power Data Logging Systems

Quality and Reliability

Texas Instruments is renowned for its commitment to quality and reliability. The SN74AUP1G79DPWR is no exception and is built to meet the stringent requirements of the electronics industry, ensuring long-term performance and dependability for your design projects.
