Overview of SN74AUP1G80DPWR

The SN74AUP1G80DPWR is a high-performance, single positive-edge-triggered D-type flip-flop with a clear input, designed and manufactured by Texas Instruments. This integrated circuit is part of TI's advanced ultra-low power (AUP) series, which is optimized for low-voltage operation while maintaining excellent speed and performance characteristics.

Key Features

• Low Power Consumption: The device is tailored for power-sensitive applications, with a typical low power consumption of 10 μA maximum I<sub>CC.
• Low Voltage Operation: It operates at a voltage range of 0.8 V to 3.6 V, making it suitable for battery-operated and portable devices.
• High-Speed Performance: Despite its low power design, the SN74AUP1G80DPWR offers a high-speed performance with a maximum t<sub>pd of 3.5 ns at 3.3 V.
• ESD Protection: The device includes robust electrostatic discharge (ESD) protection, ensuring reliability and longevity in harsh environments.
• Small Footprint: Housed in a small TSSOP package, it is ideal for space-constrained applications.

Applications

The SN74AUP1G80DPWR is versatile and can be used in a wide array of electronic systems, including:

• Mobile phones and personal digital assistants (PDAs)
• Portable media players
• Low-power handheld computing devices
• Data storage devices
• Medical monitoring equipment
• High-efficiency power management systems

Technical Specifications

• Logic Type: D-Type Flip-Flop
• Output Type: Non-Inverted
• Propagation Delay Time: 3.5 ns at 3.3 V
• Operating Temperature: -40°C to +85°C
• Mounting Type: Surface Mount
• Package / Case: TSSOP

The SN74AUP1G80DPWR is a testament to Texas Instruments' commitment to providing advanced electronic components that meet the needs of modern, power-efficient, and space-sensitive designs. Its combination of low power consumption, high-speed operation, and small package size makes it an excellent choice for designers looking to optimize their systems for both performance and power efficiency.
