Product Overview: SN74HCT14DRG4 by Texas Instruments

The SN74HCT14DRG4 is a high-performance, hex Schmitt-trigger inverter integrated circuit from Texas Instruments, designed to provide optimal solutions for a wide range of digital and mixed-signal applications. This device features six independent inverters with Schmitt-trigger inputs, making it particularly suitable for transforming slowly changing input signals into sharply defined, jitter-free output signals, enhancing noise immunity and mitigating erratic outputs caused by slow transition rates.

Key Features

• Logic Type: The SN74HCT14DRG4 is based on CMOS technology, ensuring low power consumption and high noise immunity characteristic of HCT logic family devices.
• Supply Voltage Range: It operates over a broad supply voltage range from 4.5V to 5.5V, making it compatible with TTL logic levels while maintaining the low power consumption of CMOS devices.
• Output Drive Capability: The device can drive up to 10 LSTTL loads, providing ample current for a variety of digital circuits.
• Package: Available in an SOIC-14 package, the SN74HCT14DRG4 is designed for space-efficient PCB layout and is suitable for automated surface-mount assembly processes.

Applications

The versatility of the SN74HCT14DRG4 allows it to be used in numerous applications such as:

• Wave shaping and noise filtering
• Signal processing
• Glitch removal on digital lines
• Pulse shaping
• Logic circuits and systems

Quality and Reliability

Texas Instruments is renowned for its commitment to quality and reliability, and the SN74HCT14DRG4 is no exception. It is designed to meet the rigorous standards of the electronics industry, ensuring long-term performance and stability in your electronic designs.

Environmental Information

The SN74HCT14DRG4 is RoHS compliant and is free from lead (Pb), ensuring that it meets current environmental standards for electronic components.
