SN74HCT244DBR Real Image SN74HCT244DBR real image6010 SN74HCT244DBR Real Image
Same model may have multiple batches, images only for reference.
SN74HCT244DBR Real Image SN74HCT244DBR real image6010 SN74HCT244DBR Real Image
SN74HCT244DBR Real Image SN74HCT244DBR real image6010 SN74HCT244DBR Real Image
Same model may have multiple batches, images only for reference.

SN74HCT244DBR

Part No SN74HCT244DBR
Manufacturer Texas Instruments
Catalog Logic - Buffers, Drivers, Receivers, Transceivers
Description IC BUFF/DVR TRI-ST DUAL 20SSOP
Datasheet
SN74HCT244DBR Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Logic Type Buffer, Non-Inverting
Number of Elements 2
Number of Bits per Element 4
Output Type Push-Pull
Current - Output High, Low 6mA, 6mA
Supply Voltage - Operating 4.5 V to 5.5 V
Temperature Range - Operating -40°C to 85°C (TA)
Mounting SMD (SMT)
Case / Package 20-SSOP
Win Source Part Number 030154-SN74HCT244DBR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian SN74HCT244DBR CAD Model

Description

The SN74HCT244DBR is a high-quality product from Texas Instruments, a renowned American technology company that designs and manufactures semiconductors and various integrated circuits.

  • Function: octal buffer and line driver
  • Outputs: three-state, inverting and non-inverting
  • Operating Voltage Range: 4.5 V to 5.5 V
  • Operation: -40°C to 85°C
  • Maximum tpd: 19 ns @ 5V
  • Drive: Up to 15 LSTTL loads
  • Compatibility: LSTTL, CMOS, NMOS, and TTL
  • Compliance: RoHS compliant
