The SN74LV1T08DBVR is a high-performance, single 2-input positive-AND gate integrated circuit from Texas Instruments, designed for use in a wide range of digital applications. This versatile logic gate is part of the LV1T family, which is known for its low-voltage operation and high-speed interface technology.

Key Features

• Operating Voltage: The device is optimized for use at 3.3 V but can handle a voltage range from 1.65 V to 5.5 V, making it suitable for interfacing with both low-voltage and standard TTL logic levels.
• Output Drive Capability: The SN74LV1T08DBVR can drive up to 32 mA at the output, allowing for direct drive of LEDs or other low-power devices.
• Low Power Consumption: With its low-power design, the device minimizes power usage, which is crucial for battery-operated and power-sensitive applications.
• SOT-23-5 Package: Encased in a compact SOT-23-5 package, it is ideal for space-constrained applications.
• High Speed: The device provides a propagation delay (t<sub>pd) typically only 5.7 ns, facilitating quick signal processing for high-speed operations.

Applications

The SN74LV1T08DBVR is suitable for a broad range of applications, including:

• Mobile Phones
• PDAs and Handheld Devices
• Portable Media Players
• Notebooks, Desktops, and Servers
• Data Communication Infrastructure
• Consumer Electronics
• Embedded Systems

Quality and Reliability

Texas Instruments is renowned for its commitment to quality and reliability, and the SN74LV1T08DBVR is no exception. It is designed and tested to meet the stringent requirements of the industrial and consumer markets, ensuring performance and durability across a broad range of environmental conditions.

Ordering Information

To purchase the SN74LV1T08DBVR or to obtain more information about pricing and availability, please visit the Texas Instruments website or contact an authorized distributor.
