Overview of SN74LVC2G86DCURE4

The SN74LVC2G86DCURE4 is a high-performance, dual 2-input exclusive-OR gate integrated circuit from Texas Instruments, designed to operate from a 1.65 V to 5.5 V V<sub>CC supply. This device is optimized for use in both 3.3 V and 5 V systems and is capable of interfacing with a wide range of signal levels due to its low input threshold voltages. It is part of the LVC family, which is known for low-voltage operation and low power consumption, making it suitable for battery-operated and power-sensitive applications.

Key Features

• Wide Supply Voltage Range: 1.65 V to 5.5 V, allowing for versatile use in various circuit configurations.
• Logic Level Translation: Capable of translating up to 5.5 V down to V<sub>CC, enabling it to interface with multiple logic levels.
• High Output Drive: ±24-mA output drive at 3.3 V, ensuring strong signal transmission over longer distances or to multiple receivers.
• Low Power Consumption: I<sub>CC is reduced to under 10 µA (max) when disabled.
• ESD Protection: Exceeds JESD 22, providing robustness against electrostatic discharge events.
• Operational Temperature Range: -40°C to 85°C, suitable for industrial applications.

Applications

The SN74LVC2G86DCURE4 is well-suited for a variety of electronic applications including, but not limited to:

• Portable and battery-powered electronics
• Logic level shifting and signal gating
• Data processing and computing
• Communication systems
• Embedded systems

Package and Quality

Enclosed in a VSON-8 package, the SN74LVC2G86DCURE4 is designed with a small footprint, making it ideal for space-constrained applications. Texas Instruments commits to high standards of quality and reliability, ensuring that this product meets stringent industry requirements for performance and longevity.

With its combination of versatility, performance, and compactness, the SN74LVC2G86DCURE4 is a valuable component for designers who require a reliable exclusive-OR logic function in their digital circuitry.
