The TCAN1463DMTRQ1 from Texas Instruments is a high-performance automotive CAN FD (Controller Area Network Flexible Data-Rate) transceiver designed to serve as an interface between a CAN protocol controller and the physical two-wire CAN bus. This device is specifically tailored for automotive applications and conforms to the ISO11898-2 (2016) standard, ensuring robust communication in challenging environments.

Key Features

• High Data Rates: Supports CAN FD data rates up to 5 Mbps, allowing for efficient communication in modern vehicles with enhanced data transmission capabilities.
• Low Power Mode: Features a low-power mode with remote wake-up capability, enabling energy-saving operations when the network is idle or in standby.
• Protection Features: Equipped with extensive protection mechanisms, including thermal shutdown, over-voltage, and under-voltage lockout, ensuring reliable operation under adverse conditions.
• ESD Performance: Excellent Electrostatic Discharge (ESD) performance with ±12kV HBM (Human Body Model) protection, safeguarding the transceiver from static electricity and transient voltage spikes.

Applications

The TCAN1463DMTRQ1 is ideal for a wide range of automotive applications, such as:

• Powertrain systems
• Chassis and safety systems
• Advanced driver-assistance systems (ADAS)
• Body control modules
• Infotainment and telematics systems

Package and Quality

The device comes in a compact 8-pin VSON package, which is suitable for space-constrained automotive applications. It is also qualified for automotive applications as per the AEC-Q100 Grade 1 standard, ensuring high reliability and performance over a temperature range of -40°C to +125°C.

Manufacturer Support

As with all Texas Instruments products, the TCAN1463DMTRQ1 is backed by comprehensive technical support and documentation, including datasheets, application notes, and design tools, to facilitate rapid development and integration into automotive systems.
