Products specifications

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Type Differential
Number of Elements 1
Output Type CMOS, MOS, Open-Collector, TTL
Supply Voltage - Operating 2 V to 36 V, ±1 V to 18 V
Voltage - Input Offset (Max) 5mV @ 30V
Current - Input Bias (Max) 0.25μA @ 5V
Current - Output (Typ) 20mA
Current - Quiescent (Max) 700μA
Temperature Range - Operating -40°C to 105°C
Mounting SMD (SMT)
Case / Package SOT-23-5
Win Source Part Number 032368-TL331KDBVR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name TL331
Introduction Date April 01, 2005
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2031
Ultra Librarian 3D Model Ultra Librarian TL331KDBVR CAD Model

Description

Overview of Texas Instruments TL331KDBVR

The Texas Instruments TL331KDBVR is a high-performance, single differential comparator that offers a blend of speed, precision, and power efficiency, making it an ideal choice for a wide range of applications. This comparator is part of the TL331 family, which is known for its reliability and versatility in various electronic circuits.

Key Features

  • Single Supply Operation: The TL331KDBVR can operate from a single power supply, ranging from 2V to 36V, or from dual supplies of ±1V to ±18V. This flexibility allows it to be used in multiple configurations and systems without the need for additional power components.
  • Low Power Consumption: Designed for power-sensitive applications, the device consumes low power, which helps in extending battery life in portable devices and reduces power costs in wired systems.
  • Fast Response Time: With a typical response time of 1.3 microseconds, this comparator is capable of fast signal processing, which is crucial for time-sensitive applications.
  • Open-Collector Output: The TL331KDBVR features an open-collector output that allows for wired-AND connections and is compatible with a variety of voltage levels, making it suitable for interfacing with different logic families.
  • Input Offset Voltage: It offers a low input offset voltage, which enhances accuracy and stability in applications where precision is key.

Applications

The TL331KDBVR is widely used across various industries, including:

  • Consumer electronics
  • Industrial measurement and control systems
  • Automotive systems
  • Data acquisition systems
  • Signal conditioning modules

Package and Quality

Encased in a small SOT-23-5 package, the TL331KDBVR is designed for space-constrained applications. It is RoHS compliant and meets Texas Instruments' standards for quality and performance, ensuring reliability even in harsh environments.

Conclusion

With its combination of features, the TL331KDBVR from Texas Instruments is an excellent choice for designers looking for a high-quality differential comparator that balances performance with power efficiency. Whether it's for consumer gadgets or industrial machinery, this component is engineered to deliver consistent, reliable operation.
