Product Overview: TLV1117-25CDCYR

The TLV1117-25CDCYR is a low-dropout voltage regulator designed by Texas Instruments, renowned for its reliability and efficiency in a variety of applications. This regulator is capable of delivering a fixed output voltage of 2.5V, with an output current of up to 800 mA, making it an excellent choice for moderate to high-power applications that require a stable voltage supply.

Key Features

• Output Voltage: The TLV1117-25CDCYR provides a fixed output voltage of 2.5V which is ideal for logic circuits and other sensitive electronic components that require a precise voltage level.
• High Output Current: With the ability to supply up to 800 mA of output current, this regulator can support a wide range of devices, from microcontrollers to small motors.
• Low Dropout Voltage: The low dropout voltage feature ensures that the regulator can maintain a stable output even when the input voltage is very close to the output voltage, thus improving efficiency and battery life in portable applications.
• Thermal Protection: The built-in thermal protection safeguards the device against excessive temperature and power dissipation, enhancing the longevity of both the regulator and the overall system.
• Overcurrent Protection: The overcurrent protection feature prevents damage to the regulator and the connected components in the event of a current overload.
• Wide Operating Temperature Range: The device is designed to operate over a broad temperature range, making it suitable for industrial and automotive applications.

Applications

The TLV1117-25CDCYR is versatile and can be used in a diverse array of electronics, including but not limited to:

• Consumer Electronics
• Industrial Control Systems
• Automotive Electronics
• Power Management Solutions
• Battery-Powered Devices

Package and Quality

This voltage regulator is offered in a compact SOT-223 package, which is not only space-efficient but also allows for optimal heat dissipation. The TLV1117-25CDCYR is manufactured to Texas Instruments' high-quality standards, ensuring both performance and reliability for critical applications.

With its combination of features, the TLV1117-25CDCYR from Texas Instruments stands out as a robust and dependable choice for designers looking to enhance the stability and efficiency of their power supply circuits.
