Product Overview: Texas Instruments TLV1704AIPWR

The TLV1704AIPWR is a cutting-edge quadruple comparator integrated circuit (IC) developed by Texas Instruments, designed to provide reliable and precise voltage level detection in a wide array of applications. This high-performance device is a part of Texas Instruments' TLV170x family of comparators that are known for their low power consumption and wide operating voltage range.

Key Features

• Wide Voltage Range: The TLV1704AIPWR operates over a broad supply voltage range from 2.2 V to 36 V, or ±1.1 V to ±18 V for split-supply operations, making it versatile for use in both low and high-voltage systems.
• Low Power Consumption: With a typical quiescent current of only 45 µA per channel, this comparator is an excellent choice for battery-powered and energy-efficient applications.
• Fast Response Time: It boasts a propagation delay typically under 10 µs, ensuring quick response times for critical signal processing tasks.
• Open-Drain Outputs: The open-drain output configuration allows for flexible voltage-level translation and the ability to wire outputs together for wired-OR logic configurations.
• Robust Design: The device features no phase inversion with overdriven inputs and is specified for operation from -40°C to +125°C, suitable for use in harsh environmental conditions.

Applications

The TLV1704AIPWR is commonly utilized in a range of applications including:

• Threshold detection and voltage monitoring
• Battery-powered and portable devices
• Window comparators
• Zero-crossing detectors
• Relay drivers
• Industrial and automotive systems

Package and Availability

This IC is offered in a TSSOP-14 (Thin Shrink Small Outline Package) that is optimized for compact PCB layouts. The part number "AIPWR" signifies the tape and reel packaging option, which is ideal for automated assembly processes. As a product of Texas Instruments, known for their commitment to quality and reliability, the TLV1704AIPWR is supported by comprehensive technical documentation and manufacturer's support.

For detailed specifications, application notes, and support tools, customers can visit the Texas Instruments website or contact their sales and support team.
