The TMS320F28069PNT is a high-performance microcontroller unit (MCU) from Texas Instruments, designed for advanced embedded control applications. This MCU is part of the C2000™ Piccolo™ family and is particularly well-suited for applications requiring a mix of signal processing and control tasks, such as in motor control, digital power supplies, and renewable energy systems.

Key Features

• High-Performance Processing: The TMS320F28069PNT is built around a 32-bit C28x floating-point CPU, providing 90 MIPS of processing power, which ensures smooth handling of complex algorithms and control functions.
• Integrated Control Peripherals: This MCU comes with a variety of on-chip peripherals that are optimized for control applications, including high-resolution PWM outputs, analog-to-digital converters (ADCs), and capture inputs.
• Enhanced Pulse Width Modulators (ePWM): The device features advanced PWM capabilities that allow for precise motor control and power conversion efficiency.
• Flexible Connectivity: With multiple serial communication interfaces such as I2C, SPI, and UART, the TMS320F28069PNT provides versatile connectivity options for various system requirements.
• Robust Design: The MCU is designed to operate reliably under harsh conditions, featuring a wide temperature range and built-in protection mechanisms.

Applications

The TMS320F28069PNT excels in a multitude of applications, including but not limited to:

• Industrial Motor Drives
• Digital Power Conversion
• Renewable Energy Systems like Solar Inverters
• Power Supplies
• Intelligent Sensing Applications

Development Support

Developers can take advantage of Texas Instruments' comprehensive suite of development tools for the TMS320F28069PNT, including Code Composer Studio™ IDE, controlSUITE™ software, and a wide range of development kits and evaluation modules to expedite the design and prototyping process.

Ordering Information

The TMS320F28069PNT is available in an 80-pin LQFP package, ensuring a compact footprint for space-constrained applications. For detailed product specifications, sample requests, and ordering information, please visit the Texas Instruments official website or contact an authorized distributor.
