Overview of TPS2113APWR from Texas Instruments

The TPS2113APWR is an advanced power multiplexer from Texas Instruments, designed to seamlessly switch between two power sources without interruption. This high-quality component is ideal for applications requiring a reliable and efficient power supply management solution.

Key Features

• Automatic Switching: The TPS2113APWR can automatically select between two power sources, making it perfect for systems that need a backup power supply or for managing power from different sources.
• Wide Voltage Range: It operates over a wide input voltage range from 2.8V to 5.5V, which allows for flexible usage in various applications.
• Low R<sub>ON Resistance: The device features a low ON-resistance of just 50 mΩ, which minimizes power loss and improves efficiency.
• Current Limiting and Thermal Protection: Built-in current limiting and thermal protection features safeguard the device and the system from over-current conditions and excessive heat.
• Bidirectional Operation: The TPS2113APWR supports bidirectional power flow, which is essential for applications like USB switches and power path controllers.

Applications

The versatility of the TPS2113APWR makes it well-suited for a variety of applications, including but not limited to:

• USB hubs and peripherals
• Handheld devices
• Portable media players
• Redundant power supply systems

Package and Quality

The TPS2113APWR is available in a compact TSSOP-8 (PW) package, which is conducive for space-constrained applications. Texas Instruments ensures the highest quality and reliability of its components, and the TPS2113APWR is no exception, adhering to stringent industry standards.

Conclusion

For designers looking for a robust power management solution, the TPS2113APWR from Texas Instruments offers the perfect blend of performance, efficiency, and reliability. Its automatic switching capability, low resistance, and comprehensive protection features make it a smart choice for ensuring smooth power delivery in a multitude of electronic devices.
