The TPS562201DDCT is a highly efficient synchronous step-down (buck) converter from the reputable manufacturer Texas Instruments (TI). This compact, integrated circuit is designed to deliver a continuous output current of up to 2 A with excellent power efficiency, making it an ideal choice for low voltage power supply applications in various electronic devices.

Key Features

• Output Current: Capable of delivering a 2 A continuous output current over a wide input voltage range.
• Input Voltage Range: Operates from an input voltage range of 4.5 V to 17 V, accommodating a variety of power sources.
• Adjustable Output Voltage: Offers an adjustable output voltage down to 0.76 V with a 1.5% accuracy over the temperature range.
• High Efficiency: Integrated low R_DS(on) power MOSFETs ensure high efficiency at both heavy and light loads.
• Frequency Synchronization: Supports synchronization to an external clock to minimize interference with other circuits.
• Thermal Protection: Features over-temperature protection to safeguard the device under extreme conditions.
• Package: Available in a compact 6-pin SOT-23 package, suitable for space-constrained applications.

Applications

The TPS562201DDCT is versatile and can be used in a wide array of applications, including:

• Consumer Electronics
• Set-Top Boxes
• Networking Equipment
• Point of Load Conversions
• Portable and Battery-Powered Equipment

Design Support

To facilitate the design process, Texas Instruments provides extensive technical documentation, including datasheets, reference designs, and application notes. Designers can take advantage of TI's WEBENCH^® Designer tools to customize the TPS562201DDCT for their specific application needs, ensuring a quick and efficient design cycle.

With its combination of performance, efficiency, and design flexibility, the TPS562201DDCT from Texas Instruments stands out as a robust solution for modern power supply designs.
