The TPS563200DDCR is a highly efficient, fast transient response, synchronous step-down DC-DC converter designed by Texas Instruments. This advanced power solution is ideal for a variety of applications, including distributed power systems, networking, consumer electronics, and industrial equipment.

Key Features

• Input Voltage Range: The device supports a wide input voltage range from 4.5V to 17V, making it versatile for different power supply scenarios.
• Output Voltage: It is capable of delivering an adjustable output voltage down to 0.6V with high accuracy, which is essential for powering today's low-voltage digital cores.
• High Efficiency: The TPS563200DDCR employs an Eco-mode™ feature that maintains high efficiency during light loads, thereby reducing power consumption and extending battery life in portable applications.
• Current Capability: This device can supply up to 3A of continuous output current, which is suitable for a range of medium-power requirements.
• Protection Features: It includes comprehensive protection features such as over-current protection (OCP), over-voltage protection (OVP), under-voltage lockout (UVLO), and thermal shutdown to ensure the longevity and reliability of the application.
• Switching Frequency: The converter operates at a fixed switching frequency of 500kHz, which allows for a balance between efficiency and component size, enabling compact power supply designs.

Design Flexibility

The TPS563200DDCR comes in a small 8-pin SON package with a body size of 3.00mm x 3.00mm. Its compact form factor is well-suited for space-constrained applications. The device also features an integrated high-side and low-side MOSFET, which reduces external component count and simplifies the design process.

Applications

With its robust feature set and design flexibility, the TPS563200DDCR is an excellent choice for powering FPGAs, DSPs, microprocessors, and other digital ICs that require a stable and efficient power supply.
